Series No:00118
Item Name:6CH DJ Mixer
Item Code:BPM6USB
Bar Code:
Brand:JBSYSTEMS
MOQ: 0 PCS
Price:USD 1-9 PCS
Price:USD 10-49 PCS
Price:USD 50-99 PCS
Price:USD 100-499 PCS
Price:USD >500 PCS
QTY:pcs
JBSYSTEMS is more than 20 years brand in Europe for professional audio equipment.
JBSYSTEMS shocked the fast growing DJ scene with a completely new mixer design.
All these product’s technologies are finally adapted to DJ’s remixing techniques through a state of the art ergonomical design and a useful set of effect functions.Fully designed so as to reply to any DJ needs
:: Product Description
* 14 inputs on 6 channels (9 line or 6line + 3phonos, 3mics, 2USB)
* 2 Bidirectional USB connections (play and record at the same time!)
* 1 separate balanced DJ mic with talkover
* Gain, treble, mid, bass controls on all channels
* Assignable and easy replaceable crossfader
* High quality, easy gliding "steel rail" DJ faders
* 2 Master outputs with individual balance controls
* Master1 with balanced XLR outputs and signal trimming
* LED VU-meters on input channels and master 1
* Very accurate automatic beat counters
* Crossfader starts for compatible CD players
* Pre-fade listening with cue mix option
:: Technical Information
*Power Supply: AC 230 V, 50Hz (34Watt)
*Frequency response: 20-20.000Hz (+/-3dB)
*THD + noise: <0.05% @ 1kHz, 0dB, load = 47kΩ
*S/N Ratio (IHF-A): >78dB @ 1kHz.
*USB connections: USB 2.0, bidirectional (44,1kHz / 16bit)
*Windows ? & MacOS ? compatible.
*USB cable (not included): Lmax = 3m
*Mic inputs: 2mV @ 3kΩ
*Line/CD inputs: 340mV @ 47kΩ
*Phono inputs: 3mV @ 47kΩ
*Record output: 775mV @ 1kΩ
*Master 1/2 output: 1.55V @ 1kΩ unbal.
*Master 1 output: 2,55V @ 600Ω bal.
*Talkover: 0dB ? -14dB
*Channel tone controls: +12dB / -26dB (70Hz, 1kHz, 13kHz)
*DJ Mic tone controls: +12dB / -12dB (70Hz, 1kHz, 13kHz)
*Headphone: 3V@32Ω
*Dimensions: 483(W) x 310(D) x 112(H) mm (19”/7U)
*Weight: 6,9kg
